Shaker Screen is one of the very often uses wear parts for drilling process. When starting the drilling process, the shaker screen is installed on the shale shaker unit to separate the solid particles in drilling fluids. The fine holes on screen panel could block the solids larger than the hole size, while the liquid could go through easily. On oil field, most of the shale shaker unit is using 3 or 4 panel screens. According to different condition of the drilling fluids and usage, the driller need make some inventory of the spare shaker screen.

GN Shaker Screen For Sale

gn shaker screen on sale

It will be good to get the shaker screen from the original shale shaker supplier so long as you are willing to spend much money on it. There is another way to get the replacement screen from the OEC screen manufacturer. This would save a lot on the cost of spare screens, so that the drilling cost would be greatly reduced.
GN Solids Control, definitely, is one of the manufacturers of the shaker screens. With nearly 10 years experience in manufacturing the solids control equipment and shaker screens, GN now could provide the replacement shaker screen for Derrick FLC 500 and 48-30 series, replacement screen for Swaco Mongoose and ALC series. No matter hook strip or frame type, pre-tensioned or non-pretensioned. Many positive onsite level performance feedbacks proved the GN’s screen quality.
It is well known GN is a manufacturer who is keeping improving the technology. After several years’ research and kindly feedbacks from customer, GN has improved the technology on shaker screen fabrication, which greatly increases the shaker screen life time and reduce the processing cost. This directly leads to the reduction of the screen price. GN is willing to share the benefit with all the clients by quoted the full line screens with a 20-30% unit price reduction. That is really good news for the shaker screen requester.
GN is also able to provide the replacement shaker screen used on Cobra shaker, VSM300 shaker and FSI shakers. Besides, GN’s does have the screens for own shale shaker unit. If you have any request on the shaker screen, just call us to get more information.

GN Solids Control deliveried the 9th range of containerized drilling waste management system with winterization to get Russian client and this is a third containerized drilling waste material management system for a identical client in Russia. Seeing that everybody knows, Russia drilling surgery always in very cold weather and want all equipment and mud tank to be working in winter. That’s why we construct many sets of drilling waste management system and also solids control equipment intended for winterization design.

Main Tools For Winterized Drilling Squander Management System
One set of containerized vertical cuttings dry remain inside of 40 feet gift basket, the vertical cuttings dryer can process drilling cuttings 30 – 50 loads per hour by 0. twenty five to 0. 5 millimeters mesh bracket. The revolving speed is 900RPM with drying efficiency make essential oil content bellow 5 pct. The oil tank capability is 48 liters, the oxygen knife installed to help stay away from screen block especially by means of water base drilling cuttings.
Three sets of mess conveyor installed, 2 units of the screw conveyor will likely be working to feed vertical cuttings dryer and the last a single for delivery the shop drilling cuttings after up and down cuttings dryer.

Two value packs of decanter centrifuge fitted, one set install VFD control panel for modify centrifuge speed from zero to 3200 RPM and also the other one is fixed velocity centrifuge on 3200 RPM. the 2 sets of decanter centrifuge installed on solids control mud tank and the centrifuge will be working to recycling going mud that out of straight cuttings dryer.
Three range of screw pump, one of them will likely be working for flushing dryer liquids outlet and the other two will be working for feeding decanter centrifuge.
All the above drilling waste management equipment place in a container and the burial container sit on the tank skid and the skid with a include installed for winterized design and style.
