Large Mud Decanter Centrifuge System for TBM engineering company

BY admin 23 August 2021 mud recycling, No Dig Mud System, Slurry separation plant

Last week, GN Solids Control finished a mud decanter centrifuge dewatering system for a TBM engineering company in China. The decanter centrifuge dewatering unit will be used to treat waste slurry from TBM drilling.

big bowl decanter centrifuge

The decanter centrifuge used in the dewatering system is a special model with very huge bowl: GNLW764A-VFD. The bowl size of the centrifuge is 760mm (30 inch) . The bowl length is up to 3328mm. It is a high speed 2-phase decanter centrifuge for liquid and solids separation. The cut point of the centrifuge is 2 ~ 5 microns. It is a dual motor centrifuge. The main drive motor used in the decanter centrifuge is 160Kw, and back drive motor is 90kw.

The chemical dosing unit used in the centrifuge dewatering unit is a very big size GNDW-6000L. The chemical dosing capacity of the unit is 6000L per hour in order to suit the big bowl centrifuge handling capacity.

The GNLW764A-VFD 30 inch big bowl decanter centrifuge is fixed inside a 40ft container, there are windows and door with access to discharge soil by screw conveyors.The GNDW-6000L chemical dosing unit is fixing on another 40ft container and lies on the top of the centrifuge container. It can minimum the footprint to save space.

Mud Cleaning system and drilling fluids decanter centrifuge for international drilling company

BY admin 19 January 2021 CBM drilling, Decanter Centrifuge, Drilling equipments Company, drilling mud centrifuge, Drilling mud system, HDD machinery, mud recycling, No Dig Mud System

A customized drilling mud processing system is is ready for shipment at GN Solids Control Beijing factory. It mud cleaning system is composted of a mud cleaner, a mixing hopper, and a centrifugal pump for mud mixing and transfer.
The drilling mud cleaning and mixing system is designed and made by client’s request to suit his drilling mud situation. Normally, mud cleaner is equipped after a pre-seperation shale shaker. But in this mud cleaning system, the first separation equipment is mud cleaner.

Drilling Mud Cleaner

The reason why the client do not use shale shaker is that, they said the solids content in the mud is not much high. And mostly are fine solids. In this case, the drilling mud can be separated by mud cleaner directly. It is to save cost. As once the shale shaker is running, clients need to replace shaker screen periodically. It is a continue cost for operation. While delete the shale shaker, the system can meet client’s request. It can save the cost of shale shaker, and furthermore, the can reduce wearing spare parts shaker screen cost.

But if the solids content is high, or the particle side is big, which is over the hydracyclone separation point and its mud handing capacity, it is better to use a shale shaker before the mud cleaner. At one hand, the shale shaker can reduce the flow rate which feed to the mud cleaner. At another hand, after the shale shaker separation, the solids content will be reduced, and the big size particle are total removed based on the shaker screen API size and cut point. It can increase the hydraucyclone separation efficient, and also to avoid the fast wear out the hydraucyclones. 10 inch desander cone and 4 inch desilter cone are the most popular cyclone sizes used for drilling fluids separation system. Operator can choose the to use only desander cone or desilter cone, or both based on the mud condition and their budgetary. Desander and / or desilter cone quality depends on the handling capacity of the whole system.

Drilling Mud Centrifuge

Feeding pump for mud cleaner is centrifugal pump. The centrifugal feed pump is located on tank slope for compact design and for maximize the total tank usable volume.

After the mud recycling and mixing system, a drilling mud decanter centrifuge is used for fine solids separation. As there will be more and more fine and ultra fine solids after some circulation of the system. Decanter centrifuge will be used to reduce the mud weight.

TBM and Pipe Jacking Slurry Separation Plant

BY admin 13 January 2021 Drilling equipments Company, Drilling mud system, mud recycling, No Dig Mud System, Piling Slurry Treatment

The TBM construction and Pipe Jacking construction drilling will generate a lot of waste water slurry which contains big percentage of sand and stones. In order to accordance with environment protection regulations and save water, project operators have to separate the TBM drilling mud, to reduce the waste and reuse the water.

GN Solids Control can design and make full package of waste water slurry separation plants. The major separation equipment in GN slurry separation plant includes: shale shaker, desander, desilter, bottom drying shaker, etc… And there are accessory items for a one-stop turn-key solution: centrifugal pump for feeding desander / desilter mud cleaner, mud tank, electrical control system, etc.

The TBM construction and Pipe Jacking construction drilling are often took in urban areas, . In this case, the TBM drilling slurry separation usually requires compact design to suit for small working area. And the TBM drilling slurry separation need to reach high treatment efficiency to treat big volume slurry. GN Solids Control TBM Slurry Separation Plant is specially designed to meet the above demands. GN Solids Control TBM and Pipe Jacking drilling slurry separation system is with a very compact foundation by optimal designing. The TBM and pipe Jacking slurry treating system can work at different height levels.

In order to meet the different requirements of different clients and different projects, clients can choose more than a set GN Solids Control TBM Slurry Separation Plant and connect them by pipelines to use them as a big flow rate handling capacity. Plus, the combination of standard modular is for fast and easy assembly. Clients can choose different modules and select the quality they need to reach the flow rate they want to reach. GN Solids Control TMB and Pipe Jacking Slurry Separation Plant to move conveniently among different work sites.

GN Solids Control TBM and Pile Jacking Slurry Separation Plant advantages:
1) Full function compact package design for One -stop Turnkey Solutions
2) Modular, pre-assembled and small footprint units for easy and fast transportation from one location to another
3) 5-Phase Separation System for finer solids separation and to get more clear water

Advantages of GN Solids Control packaged drilling mud system

BY admin 4 December 2020 CBM drilling, Diamond Drilling, Drilling mud system, HDD machinery, Microtunneling slurry separation, mud recycling, No Dig Mud System, Piling Slurry Treatment

GN Solids Control is one of the well-known International Brand for drilling Mud Solids Control System & Drilling Waste Management system. GN Solids Control offers the one stop solution for Solids Control treatment of oil gas drilling, CBM drilling, HDD, and water well drilling as well as the construction drilling mud treatment etc.

Nearly all drilling mud processing equipment containers shaker screen separation. Replacement shaker screen is a major wearing spare parts for drilling mud system. And it is a big and continue cost. GN Solids Control is specialized in high quality replacement shaker screen for various popular shaker models. GN Solids Control has his own R&D department for shale shaker screens. Clients can also contact GN Solids Control to make customized shaker screen.

Most solids control equipment manufacturer only make some kinds of processing equipment. Like some companies make shale shaker, mud cleaner and agitators, but they are not capacity to make decanter centrifuge or cuttings dryers. Some companies are only capacity to make centrifuges for various industries, they cannot make solids control separation equipment, like shale shaker, mud cleaner, degasser, etc…While some companies are only make pumps, they cannot make separation equipment. And there are some companies only make mud tanks, they are not capacity to make solids control separation equipment by themselves.

GN Solids Control is focusing on full line solids control equipment for various drilling mud. GN Solids Control is specialized in drilling mud liquid and solids separation. All the separation equipment are made by GN Solids Control. In this case, GN Solids Control knows more about the separation equipment, and can offer more reasonable proposal.

Furthermore, electrical control system is another essential point for separation equipment, especially VFD smart control panels for decanter centrifuges. GN Solids Control has his own electrical control department. GN Solids Control electrical engineering business department has comprehensive ability to provide solution for explosion-proof electrical control. GN is able to provide the electric control system, explosion-proof electrical enclosure design and development, fabrication, site installation, program debugging, and other services.

GN Explosion Proof Certification: GN Solids Control electrical control products have been certified by China National standard CNEx, International standard IECEx and European standard ATEX certificate, which enable GN’s products to meet high level market requirements.

Small Solids Liquid Separation Unit for Europe Client

BY admin 27 September 2020 CBM drilling, Decanter Centrifuge, Diamond Drilling, Drilling Fluids shale shaker, drilling mud centrifuge, Drilling mud system, mud recycling, No Dig Mud System, Slurry separation plant

GN Solids Control made a small liquid and solids separation system. The small system is customized for an Europe company per clients request. The client asked for a small recycling unit with cleaning capacity of about 12-15 m³ / hour. The client wants a small single centrifuge in the small recycling system.

GN Solids Control customized a compact system which is composed of a small size shale shaker and a mini size decanter centrifuge. The shale shaker and decanter centrifuge are located on a mud tank together with a centrifuge feeding pump and electric control cabinet for the whole system. Tank size for the whole system is 3900Lx2250Wx1300H (mm) for easy movement. It is a small capacity recycling system with turn-key solution. All connections inside the system are included.

The Shale shaker separator model is GNZS752F-MDZF. It is a 2-panel small size shale shaker with small footprint.

The Decanter centrifuge model is GNLW223D-VFD. It is a 9” baby centrifuge for fine solids separation. The Cut point of GNLW223D-VFD centrifuge is 2 ~ 5 microns.

The color, brand and logo are all customized per client’s request. GN Solids Control is capable to make other customized system per clients job site situation. Clients can contact GN Solids Control sales engineer to get customized solutions.

Besides the small mud recycling system, GN Solids Control makes various sizes of Mud Recycling System for HDD, water well drilling, Trenchless, Piling and TBM activities.

The major applications of GN mud recycling system covers below field, but not only limited to below:
1) Trenchless HDD Project
2) Bored Pile Project
3) Micro TBM (Tunnel Boring Machine)
4) Diamond Drilling, Water Well Drilling etc

Below are some Mud Recycling desanding plant Models GN can make:
D Series Mud Recycling Models:
1)GNMS-200D Capacity: 200GPM, 50m3/h
2)GNMS-500D Capacity: 500GPM, 120m3/h
3)GNMS-1000D Capacity: 1000GPM, 240m3/h
4)Other models should be customized per clients’ request

GN Non Oil Drilling Mud Recycling System is Widely Used

BY admin 6 November 2016 HDD machinery, Microtunneling slurry separation, No Dig Mud System, Piling Equipment, Piling Slurry Treatment, solids control, Solids Control Equipments

The business of today’s GN has been divided mainly into 2 scopes, one is the normal drilling mud recycling, and the other is the waste management including the waste coming from petroleum related and other separation industries. This blog is mainly talking on the drilling mud recycling system that used in non oil drilling industry.
In oil drilling, the drilling depth and safety regulation request large drilling mud storage and more solids control equipment. Thus, the mud recycling system is always equipped with degasser unit and large volume mud tanks.

HDD Mud Recycling System

Comparing with the mud recycling for oil industry, the unit for non oil drilling is more compact and less equipment needed.

Trenchless/No Dig HDD project – The mud recycling system used in this type drilling is matching with a No dig rig. In some project for long distance pipeline and cables laying underground, it is inconvenient to dig an open groove on the ground as that will interrupt the normal traffic. The trenchless is an ideal choice. The mud recycling system for this project is always consisting of 3 stages separation as shale shaker unit, de-sanding and de-silting cyclone.
Piling is the main method to install the bridge supporting pillar. A de-sanding unit with a small tank would be enough to remove out the coarse solids from the drilling fluids. The de-sanding unit is a composition of de-sander cyclone and shaker unit that can separate out the solids with size of 40-70 microns. Piling does not request very clean mud; less equipment involved makes the recycling unit for piling is very compact.
GN also can manufacture the mud recycling system for tunneling project. For micron tunneling, GN has model available with capacity of 120m3/h, 240m3/h and 500m3/h. For large flow rate request, GN has the mud plant GNMS -3600M with treating capacity of 3600m3/H.

Tunneling Mud De-sanding Plant

Besides, GN’s mud recycling system can also be used in water well drilling, coal bed methane exploration, dredge slurry separation and the mining flushing waster cleaning process.

Self-contained 200GPM Drilling Mud Recycling System for HDD

BY admin 19 June 2015 CBM drilling, Drilling Fluids shale shaker, Drilling mud system, HDD machinery, No Dig Mud System, solids control, Solids Control Equipments

For the upcoming no dig show this September in Australia, GN solids control would like to show there one set self-contained 200 GPM drilling mud recycling system for HDD projects. As a leading manufacturer especially for drilling mud recycling equipment, besides the large footprint mud system for oil drilling, GN solids control could also provide compact structure design mud recycling system.
According to the HDD rig mud flow, GN’s economic mud systems are classified as 150/200GPM, 350GPM, 500GPM, 800GPM/1000GPM and 1500GPM. Just like the unit of 200GPM would be shown in Australia, though it is small footprint, it has all necessary functions for drilling mud recycling and mud re-configuration.

2015.6.19 gn 200 gpm compact mud system for hdd (1)

200 GPM HDD Mud System

Below is the equipment list for the 200GPM unit
1. GNZY753-4N shaker and de-silter composition unit which has the functions for first stage primary solids separation and second stage for drying the solid discharged from the 4” cyclones. This unit has a top located buffer box for well back drilling mud feeding, the bottom layer screen of this unit remove the coarse solids, liquid goes through the mesh screen opening and gets down to the storage tank. Pumped by a 15hp centrifugal pump, the liquid was transferred to the de-silter cone for fine solids removing. The upper layer screen with much finer opening would block and separate out the finer solid cuttings.
2. GNSLM20A-110 Jet mud mixer is used for adding the mud chemicals and re-configuration of the drilling mud. The beneath located mud tank was divided into 2 compartments and one of them is used for mixing and storing the active drilling mud. The mixing pump adopted is same with the one for feeding to de-silter cones. That would be much easier for future maintenance and parts replacement. The mixing pump could also be used as discharging pump for transferring the active mud to the rig.

2015.6.19 gn 200 gpm compact mud system for hdd (2)

Compact Design Mud System

GN also has more compact unit for de-sanding, by connecting the de-sanding unit with a customized mud tank, the operator could run the mud recycling system more fit their own project condition. For more information on GN compact mud system, you may contact with GN team without hesitate.

Compact Mud Recycling Unit for Piling Project

BY admin 5 April 2015 CBM drilling, Drilling equipments Company, Drilling Fluids shale shaker, Drilling mud system, HDD machinery, Microtunneling slurry separation, Mud Mixing, No Dig Mud System, Piling Equipment, Piling Slurry Treatment, shale shaker, Slurry separation plant, solids control, Solids Control Equipments, Uncategorized

As per the feedback from the customers who are engaging in the pilling business, GN designed and perfect the economic mud recycling system specially for the drilling mud cleaning application in piling project. On the consideration of limited location area of the piling project job site, GN’s piling mud recycling system is designed with a very compact structure but with full functions for drilling mud recycling.

De-sanding Unit

Below is the standard configuration of piling mud recycling system with treating capacity of 500GPM.
Model: GNMS500-D
Flow Rate: 500 gallons per minute
Cyclone Specs.: 1 pc 10” de-sanding cyclone made from 100% polyurethane
Screen Specs.: Shale shaker with up and down 2 layers screen with total screen area of 2.23m2
Feeding Pump: Mechanical seal type centrifuge pump of 50 HP used to feed mud to the de-sanding cyclone
Cut Point: Solids Removable down to 40 microns
Catching Tank: Under located catching tank for mud storage. The tank is equipped with lighting system and ladders for easy operation.
Electrical Control System: Explosion, water, and dusty proof electrical control panel with SIEMENS or Schneider components

GN also has the model of GNMS200-D and GNMS1000-D available and the treating capacity is separately 200GPM and 1000 GPM.
The advantage of this type mud recycling system is cost competitive. By connecting with storage tank and mud mixing hopper, this de-sanding unit could also be used in other kind of project like the small horizontal directional drilling, micro tunneling and water well drilling.

Economic Mud Recycling Unit Layout

GN recommends the layout of this economic mud recycling system:
1) Mud Pit
2) Submersible Slurry Pump
3) Mud Recycling System
4) Storage Tank
5) Outlet Pipe
6) Jet Mud Mixer.
GN Solids Control also offers submersible slurry pump, mud storage tank, as well as jet mud mixer per request.
GN is now on promoting this type economic mud recycling system, for more information, you may sent inquiry to sales@gnsolidscontrol.com

500GPM mud cleaning system equipment

BY admin 12 October 2013 CBM drilling, Drilling equipments Company, Drilling Fluids shale shaker, Drilling mud system, HDD machinery, No Dig Mud System, shale shaker, Solids Control Equipments

500GPM is a very common capacity for mud cleaning system. How to choose the right equipment for 500GPM mud system system.

Below is a standard proposal from world top solids control specialist – GN Solids Control. GN now have a complete set 500GPM mud cleaning system in storage for sale:

Solids Control Equipment for the 500GPM mud cleaning System

1) One Linear Motion Shale Shaker GNZS703
2) One Mud Cleaner with Desander / Desilter
3) Centrifugal Pumps 6×5 (37kw) for feeding to desander/ desilter
4) 40 Feet Size length and width ISO container size with fast fixing on trailer.
5) Centrifugal pumps completed with mixing hoppers for you drilling mud mixing.
6) Transfer function for transfering clean mud to the drilling rig mud pump.
7) Mud Agitators and Mud guns for agitation of the mud.
8) High quality mud tank attachment for easy operation and safety, Handrails can be fold up to the side of tank without removing during shipment.

Mud tank size for the mention proposal of 500GPM mud cleaning system is a common standard; it can meet the shipment limitation of most countries. GN can also customize other tank size per customers’ requirement on tank storage capacity.

For equipment, GN can also change other model per different requirements of different jobsite. For some jobsite, they may only need separate desander and desilter without the underflow shale shaker, it is also option.

For a more exact proposal, no hesitate to contact GN Group now.

Mobile mud system for HDD drilling rig to Kazakhstan

BY admin 17 August 2013 CBM drilling, Drilling equipments Company, Drilling Fluids shale shaker, Drilling mud system, HDD machinery, No Dig Mud System

Last week, China top solids control Manufacturer: GN Solids Control exported a complete mobile unit mud system to Kazakhstan. It is a 500GPM mobile mud system specially designed and made for DHH drilling rigs.

Mobile mud system is a kind of fast movement system. GN Solids Control have much experience on mobile mud system used for HDD drilling rigs.

Strong points of GN 500GPM mobile mud system for HDD drilling rig:

1) Mud tank with same dimension with 20 feet container

2) The mud system is separated with the mobile skid. It can be taken off and used as skids mud system

3) Linear motion shale shaker. With the same shaker screen with Swaco Mongoose shaker

4) Centrifugal feeding pump interchangeable with NOV Mission pump

3 stages solids control equipment including in the 500GPM mud system:

1) GNZS594 linear motion shale shaker, 1 set (interchangeable shaker screen with Swaco Mongoose)

2) GNZJ594-2S12N mud cleaner, 1 set

3) Jet mud mixer, 1 set

4) Centrifugal sand pump 2 sets feeding for mud cleaner (desander and desilter)

More for information on GN500 GPM HDD mud system mobile unit, or if you have any inquire on HDD recycling mud system, contact GN group at Email: Sales@gnsolidscontrol.com
