Category: Drilling mud system

Contaminated Soil and Oil-Based Mud Cutting Treatment Systems

GN Solids Control is a leading name in the design and manufacturing of oil – based mud (OBM) cutting treatment systems. GN can send our engineers for the first – time installation and commissioning to ensure a smooth start – up for our clients.​

Key Separation Equipment​
Vertical Cuttings Dryer​
The vertical cuttings dryer is the star of our OBM cuttings treatment lineup. It is the primary separation equipment for OBM cuttings treatment and is highly efficient. With this advanced technology, it can reduce the Oil on Cuttings (OOC) to an impressively low range of 3 – 5%. This significant reduction not only helps in waste management but also has cost – saving implications for the oil and gas industry.​
High G Drying Shaker​
While the high G drying shaker is mainly designed for water – base mud cuttings, some clients have also used it for OBM cuttings. However, it has its limitations. It can only reduce the OOC to around 10%. This makes it clear that for optimal OBM cuttings treatment, the vertical cuttings dryer is the better choice.​


High – Speed Centrifuge​
High – speed centrifuge plays a crucial role in the treatment process. It is used after the vertical cuttings dryer. Its function is to reduce the mud weight and make the mud qualified for reuse. By recycling the mud, we not only save resources but also contribute to a more sustainable drilling operation.​
Treatment Locations​
It understand that every client has different operational setups. Some may choose to treat the cuttings at the rig site, while others prefer to collect the cuttings and treat them in their yards. To better serve clients, GN Solids Control will send a question list on waste management in investigate the project information and demands. This will enable GN to offer clients more tailored and proper solutions.​

GN Solids Control Solutions​
Solution 1: Vertical Cuttings Dryer and High – Speed Centrifuge Package​
This package is an excellent choice for treating fresh OBM cuttings at the rig site. It is relatively easy to implement and highly effective. With this solution, our system can reduce the OOC to the 3 – 5% range, ensuring efficient waste reduction right at the source.​


Solution 2: Oily Sludge Separation System for Old Oily Sludge in Waste Pits​
For the old oily sludge in waste pits, we offer the oily sludge separation system. We have a successful project reference in Qatar that showcases the effectiveness of this solution.
In this project, the results were remarkable:​
Oil on Solids: 1 – 3%​
Water in Oil: 3 – 5% (BS&W)​
Oil in Water: 1%​

GN Solids Control OBM cuttings system is a waste – reducing system that can be used before TDU (Thermal Desorption Unit) to improve TDU efficiency.

3000HP Drilling Rig Solids Control System for Asia Drilling Company

A 3000HP drilling rig requires high standards for drilling mud solids control equipment due to its larger scale and more demanding operational needs. GN Solids Control designs the mud system to accommodate larger volumes of drilling fluids and ensure efficient solids control throughout the drilling process.

The mud system includes an 80bbl trip tank, complete with a centrifugal trip pump. The trip tank features a level meter with a 0.5bbl level indicator, ensuring precise monitoring of the mud volume. There are three active mud tanks in the system: a shale shaker tank, an intermediate tank, and a suction tank, each with a 500bbl capacity. These tanks are essential for maintaining the right balance of drilling fluids during operations.

In addition, the system includes four reserve tanks for mud storage, with a total capacity of 2000bbl. The setup also includes three water tanks and a 70bbl pill tank to support various operations and drilling fluid maintenance.

A comprehensive mixing system is integrated into the mud system for deep drilling rigs. The mixing system consists of two mixing hoppers, three centrifugal mixing pumps, and one shearing pump for use and backup. This setup ensures that drilling fluid is mixed effectively to maintain consistent viscosity and performance.

To handle the high flow rates and large volumes of drilling fluid, the system uses three sets of GNZS596K double-deck shale shakers. These shakers are specifically designed for large-capacity applications and utilize the same size replacement screens for both the upper and bottom decks, ensuring ease of maintenance and consistent performance.

After the shale shakers, the system includes a 1500GPM mud gas separator, a vacuum degasser, and a mud cleaner to further treat the mud and remove gases, solids, and contaminants. 100hp centrifugal pumps are used to feed the desander and desilter units, ensuring proper flow rates and efficient separation of fine solids.

The system is also equipped with necessary mud agitators and mud guns to keep the mud in suspension and maintain optimal fluid properties during the drilling process.

This comprehensive mud system ensures that the 3000HP drilling rig operates efficiently, with advanced equipment for solids control, fluid management, and waste disposal.

Drilling Mud Rycycling Unit and Hydraulic Centrifuge for Overseas Client

The 500GPM mud recycling system has emerged as a workhorse solution for trenchless drilling operations in Horizontal Directional Drilling (HDD) and Coal Bed Methane (CBM) projects. GN Solids Control, a leading provider of solids control equipment, recently delivered a comprehensive 500GPM system tailored for an international client, showcasing its expertise in engineered solutions for complex drilling environments. This integrated system features a three-stage separation process housed within a robust action tank, combining primary solids removal via shale shaker with advanced fluid purification through a high-capacity mud cleaner.

At the heart of the system lies a dual centrifugal pump configuration strategically positioned on the tank’s inclined surface. These pumps ensure efficient feed distribution to both desilter and desander cones within the mud cleaner, enabling precise separation of particles down to 15μm. The modular design incorporates a lifting frame skid that supports the shale shaker and mud cleaner assemblies, facilitating rapid deployment and relocation between job sites—a critical advantage in dynamic trenchless drilling operations. Constructed from corrosion-resistant materials and equipped with adjustable baffles, the tank optimizes fluid dynamics while withstanding harsh drilling conditions.

Complementing this system, GN Solids Control engineered a full hydraulic centrifuge package specifically for coal mining applications. The GNLW223D-FHD mini-centrifuge represents cutting-edge technology in compact solids separation, capable of processing 15-25m³/h with exceptional separation efficiency. This unit integrates a dedicated holding tank and advanced control panel featuring PLC-based automation for real-time monitoring and parameter adjustment. Designed for continuous operation in demanding coalbed methane environments, the system’s compact footprint makes it ideal for space-constrained drilling locations while maintaining industrial-grade durability.

Both systems exemplify GN’s commitment to innovation and customization. The 500GPM solution incorporates API-compliant components and dual redundant safety features, ensuring compliance with international drilling standards. Meanwhile, the coal-specific decanter centrifuge package demonstrates the company’s ability to adapt technologies across different energy sectors. From shale gas exploration to underground coal mining, these systems enhance operational efficiency by reducing drilling fluid waste, controlling solids contamination, and minimizing environmental impact. With over two decades of experience serving global energy markets, GN Solids Control continues to set benchmarks in solids control engineering through its integrated solutions and client-centric approach, reinforcing its position as a trusted partner for complex drilling challenges worldwide.

Vertical Cutings Dryer and Centrifuge Unit for Africa Waste Management Company

Many clients have been loyal to GN Solids Control for years, and one such client in Africa has recently received a full-package drilling cuttings treatment system. This client has been working with GN for over 10 years, and all their drilling rigs are equipped with GN brand drilling waste management systems. The latest package includes two high-speed centrifuges, a vertical cuttings dryer, centrifuge feeding pumps, a vertical cuttings dryer flush pump, screw conveyors for cuttings transfer, centrifugal pumps, and vertical slurry pumps for mud and liquid transfer.

The high-speed decanter centrifuges are equipped with Variable Frequency Drive (VFD) control panels, which feature explosion-proof control air conditioners for self-cooling. The air conditioning units are fitted with filters that clean and dry the air before it is fed into the VFD panel, ensuring that the VFD and its components are protected from high moisture and hazardous environments. This design enhances the reliability and longevity of the equipment, even in challenging conditions.

One of the centrifuges is used in the drilling mud solids control system to reduce the mud weight, while the other is used with high speed and high G-force to recover and reduce the mud weight from the vertical cuttings dryer. Both centrifuges are mounted on telescopic skids, and the vertical cuttings dryer is mounted on a heavy skid with holding tanks, making the system easy to transport and install.

Over the course of more than 10 years of collaboration, this client has purchased over 20 full-package drilling waste management systems from GN Solids Control. The company has consistently provided high-quality solids control and drilling waste management equipment, which has played a crucial role in improving the efficiency and sustainability of the client’s drilling operations.

GN Solids Control is dedicated to offering complete solutions for solids control and drilling waste management. Clients can reach out to GN’s sales engineers for expert advice and customized solutions tailored to their specific needs. With a commitment to quality and customer satisfaction, GN continues to be a trusted partner in the oil and gas industry.

GNZS752K Mini Shale Shaker for Brazil Company

GN Solids Control has recently exported a number of mini shale shakers, the model is GNZS752K, to a reputable drilling company in Brazil. This compact and efficient shale shaker is specifically designed for work over rig mud systems, combining a small footprint with robust performance to meet the challenges of drilling operations in confined spaces.

The GNZS752K mini shale shaker features a 2-panel design that maximizes screening area while minimizing overall size. This makes it an ideal choice for drilling rigs where space is at a premium. The shale shaker is engineered with precision to ensure efficient operation and reliability, even in the most demanding environments.

In addition to the GNZS752K mini size shale shaker, GN Solids Control offers a wide range of larger shale shaker models to cater to the diverse needs of the drilling industry. These include 4-panel and 5-panel models, providing increased screening area for higher capacity operations. The larger shale shakers are available in both single deck and double deck configurations, allowing for flexibility in processing different types and volumes of drilling mud.

Beyond shale shakers, GN Solids Control’s product range extends to include a comprehensive suite of solids control equipment. This includes mud cleaners, decanter centrifuges, vacuum degassers, and hydrocyclones, all designed to work seamlessly together to provide a complete solids control solution. The company’s mud cleaners, for example, are designed to remove fine solids and excess liquids from drilling mud, improving its quality and performance.

GN Solids Control’s decanter centrifuges are engineered to separate drilling fluids from cuttings and other solids, ensuring that the drilling mud remains clean and effective. The vacuum degassers, on the other hand, are used to remove entrained gases from drilling mud, which can improve its rheological properties and stability.

Overall, GN Solids Control’s product range offers a comprehensive solution for solids control in drilling operations. From mini shale shakers to advanced mud cleaners and centrifuges, the company’s equipment is designed to improve the efficiency and performance of drilling mud systems, ultimately leading to better drilling outcomes. With a focus on innovation and quality, GN Solids Control continues to set the standard in the solids control industry, and its export of mini shale shakers to Brazil is just one example of its global reach and commitment to excellence.

Successful Installation and Commissioning of Multiple Drilling Rig Mud Tank Systems

Before the Chinese Lunar New Year holiday, the GN Solids Control team worked diligently to shorten the production time for multiple sets of drilling rig mud tank systems. Understanding the importance of timely delivery, the team put in significant effort to ensure that all systems were completed ahead of the regular schedule. Thanks to their hard work and dedication, all systems were finished on time and shipped to the rig companies before the New Year holiday, ensuring no delays for their customers.

The mud systems provided by GN Solids Control are designed for a wide range of drilling rigs, including high-power rigs like the 9000hp and 7000hp models, making them suitable for deep drilling operations. These systems are meticulously engineered to meet the needs of various types of drilling projects, ensuring efficiency, reliability, and performance in challenging drilling conditions.

GN Solids Control offers a full-package solution for oil rig mud systems, which includes key components such as pre-separation shale shakers, desanders, desilters, mud cleaners, decanter centrifuges, and jet mud mixing tanks. Additionally, the company provides full system design services, ensuring that each solution is tailored to meet the specific needs of the client’s drilling operations. This comprehensive approach helps customers streamline their operations and improve overall mud management efficiency.

One of the standout features of GN Solids Control is its ability to offer customized solutions. The company can produce mud systems with personalized color schemes and logos based on the client’s branding requirements, providing a professional and unique appearance for each system. This flexibility enhances the customer experience and ensures that each system aligns with the client’s preferences and operational standards.

By providing high-quality products, timely delivery, and customized solutions, GN Solids Control continues to strengthen its reputation as a reliable provider of drilling rig mud systems. Their commitment to excellence and customer satisfaction remains at the core of every project they undertake.

GNMS-1000 HDD Mud Cleaning System for overseas drilling company

GN Solids Control has successfully completed a GNMS-1000 HDD mud cleaning system for a Horizontal Directional Drilling (HDD) project. This advanced mud cleaning system has a handling capacity of 1000 GPM, specifically designed to optimize performance and efficiency in HDD operations.

The system is composed of several key components, each tailored to meet the unique needs of HDD projects. It includes a high-performance shale shaker, a mud cleaner, a jet mud mixing system, and a holding tank, all engineered to deliver optimal mud treatment and separation.

The mud cleaner is a combined unit that integrates a shale shaker along with desander and desilter cones. This combination ensures a multi-stage separation process, effectively removing solids from the drilling fluid. The desander cones remove larger particles, while the desilter cones handle finer solids, ensuring the drilling mud remains clean and well-maintained throughout the operation.

The two shale shakers are connected via a mud distribution box, which helps evenly distribute the mud across both units. The shale shakers are controlled by valves, allowing operators to manage the flow and separation process efficiently. This setup enables precise control over the mud cleaning process, enhancing the overall efficiency of the system.

In addition to the shale shakers and mud cleaner, the system is equipped with a jet mud mixing system, which ensures the consistent preparation and mixing of drilling fluid. The holding tank provides ample storage for the cleaned mud, ready to be reused in the drilling operation.

This complete mud cleaning system is designed to handle the rigorous demands of HDD projects, providing effective solids control and maintaining the quality of drilling fluid. GN Solids Control’s GNMS-1000 system is a reliable, efficient solution that supports smooth operations in various HDD applications, from trenchless drilling to utility installation. With this advanced system, GN Solids Control continues to provide top-tier equipment for the oil and gas, water well, and other drilling industries.

Track Mounted Mud Treatment System for Australia Customer

A complete track-mounted mud system has successfully passed its running test and is now ready for dispatch to an Australian customer. This highly versatile mud treatment system combines several key components, designed for maximum mobility and efficiency in challenging environments. It was designed and made by GN Solids Control.

At the heart of the system is a combination of shale shaker and desilter hydrocyclone assembly, which are essential for efficient mud separation. These units are accompanied by a feeding pump, a small mixing hopper, and a mixing pump, ensuring the system is capable of handling the full spectrum of mud treatment needs. Additionally, the entire system is controlled by an integrated electrical control system, which allows for easy operation and monitoring of all components. The system also features a built-in lighting setup, ensuring optimal visibility even in low-light conditions.

To provide the necessary power for operations, the system is equipped with a small generator, which ensures that all components run smoothly and independently, regardless of external power sources. All of the equipment is mounted on a compact mud tank, which is designed for easy transport and storage. The system is further enhanced by a trailer skid, offering both stability and mobility during transport and setup. Hydraulic jacking legs are included to provide secure positioning on uneven terrain, offering added stability during operation.

One of the key features of this track-mounted system is its advanced mobility. The system can be moved forward or backward using a remote control, which provides excellent maneuverability in difficult terrains. It is also capable of turning and climbing slopes, making it suitable for a wide range of road conditions and environments.

Track-mounted mud treatment systems are commonly used in geothermal well drilling, water well drilling, and other trenchless projects. Their compact design, combined with powerful mud treatment capabilities and enhanced mobility, makes them ideal for operations in remote or difficult-to-access locations. This system’s versatility and efficiency ensure that it will meet the demanding needs of the Australian customer in a variety of challenging drilling environments.

GN New Separation Equipment Showroom

GN Solids Control is a prominent company specializing in the production of oilfield solids control equipment, drilling waste management systems, and mining screen separation solutions. Recognized as a National Level Key Small Giant Company, GN Solids Control stands out in China’s industrial landscape, with only a few hundred companies achieving this prestigious designation. Within Hebei Province, GN is one of just two enterprises to receive such recognition, further solidifying its status as a leader in its field.

Since relocating to its new, advanced design factory in October 2023, GN Solids Control has entered an exciting new stage of development. This strategic move allows the company to expand its production capabilities, streamline operations, and enhance its research and development efforts, positioning it for continued growth and innovation in the industry.

One of the company’s most significant milestones in 2024 has been the completion of its new showcase room. This meticulously designed space serves as a comprehensive display of GN Solids Control’s cutting-edge technology and product offerings. The showcase room is a pivotal resource for clients, allowing them to engage with GN’s wide range of solutions in a hands-on, interactive environment.

The room is designed to provide an immersive experience, helping visitors easily understand the complexities of GN’s equipment and the benefits they offer in solving common industry challenges. It features working models of oilfield solids control systems, drilling waste management equipment, and mining separation solutions, enabling clients to see firsthand how these systems operate in real-world scenarios. By offering a tangible demonstration of GN’s products, the showcase room enhances client understanding and confidence in the company’s capabilities.

Moreover, the showcase room is not only a tool for product demonstration but also serves as a key space for client meetings, training sessions, and technical discussions. It plays a central role in GN Solids Control’s commitment to customer education and building strong, lasting relationships with clients, ensuring they receive the best possible solutions for their needs. This new development reflects the company’s dedication to growth, innovation, and providing exceptional value to its customers.

Trailer mounted mud tank units and screw conveyor for Kuwait Clients

Recently, GN Solids Control has completed the production of trailer skid-mounted mud tank systems and screw conveyors for clients in Kuwait. These systems are designed with mobility in mind, allowing for fast and efficient relocation on-site. The mud tanks are mounted on the trailer skid, which ensures ease of transport and setup while adhering to the Kuwait Oil Company (KOC) standards. This design ensures that the equipment is not only highly functional but also compliant with the strict safety and operational guidelines set by KOC.

In addition to the mud systems, GN Solids Control has manufactured screw conveyors for another Kuwait-based client. These conveyors are specifically designed to meet KOC’s stringent safety requirements for auger systems. GN Solids Control ensures that each auger is built to comply with KOC specifications while surpassing industry standards for safety and performance. This allows clients to benefit from equipment that is not only compliant with local regulations but also optimized for durability and efficiency in demanding drilling environments.

Furthermore, GN Solids Control offers a full line of solids control equipment, drilling waste management solutions, and high-quality replacement shaker screens. The replacement shaker screens are made with composite frames, ensuring enhanced durability, longer life, and better performance in the most challenging drilling conditions. The use of composite materials allows the screens to be lighter, more resistant to wear and tear, and capable of handling high volumes of drilling fluids without compromising performance.

With a comprehensive range of solids control and waste management equipment, GN Solids Control provides turnkey solutions for the oil and gas industry. The company’s commitment to meeting local standards, such as KOC’s, while maintaining high-quality manufacturing practices, makes it a trusted partner for clients in Kuwait and around the world. Through continuous innovation and attention to detail, GN Solids Control supports efficient, sustainable, and safe drilling operations.
